NDA8
Category: NDA Angle Brackets
| Request Quote | Quantity |
Line Drawing - Click to Enlarge
Product Details
| A (in) | 8 |
| B (in) | 4 |
| C (in) | 2.000 |
| D (in) | 4.000 |
| E (in) | 1.310 |
| F (in) | 7.810 |
| G (in) | 18 |
| H (in) | 1.500 |
| I (in) | 5 |
| J | 3/8-16 |
| K (in) | 6 |
| L (in) | 8.500 |
| M (in) | 0.410 |
| N (in) | 2.120 |
| O (in) | 3.750 |
| Acme Lead Screw | 3/4-10 |
| Approx Weight (lbs) | 58 |
| Documentation | |
| Download PDF |
|
