| Request Quote | Quantity |
Line Drawing - Click to Enlarge
| A (in) | 4 |
| B (in) | 2 |
| C (in) | 1.190 |
| D (in) | 2.250 |
| E (in) | 1.310 |
| F (in) | 5.120 |
| G (in) | 10 |
| H (in) | 0.500 |
| I (in) | 3 |
| J | 1/4-20 |
| K (in) | 4 |
| L (in) | 4.500 |
| M (in) | 0.280 |
| N (in) | 1.250 |
| O (in) | 1.500 |
| Acme Lead Screw | 1/2-10 |
| Approx Weight (lbs) | 17 |
| Documentation | |
| Download PDF |
|
To request a quote, please contact us using the contact form. If you have an item that we can repair for you, click the repair request forms below. Use our product configurator to download a drawing to use in your design.
If you you would like to reach us directly, give us a call at 262-377-2434, or email us at sales@gilmanprecision.com.
